    Bottles Monoblock Filler Capper Machine 700-1200BPH Powder Filling Machine

    Ask Lasest Price
    Brand Name : TOM
    Model Number : FJ-2BP
    Certification : CE, ISO,CO
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 15 sets per month
    Delivery Time : 30 working days
    • Product Details
    • Company Profile

    Bottles Monoblock Filler Capper Machine 700-1200BPH Powder Filling Machine

    FJ-2BP Fully Automtaic PLC Controlled powder packing machine for Bottles
    Major characteristics

    This type of packing machine is automatic controlled by PLC. Movement reliability, servo motor, touches screen, easy operation, and adjustable speeds. This type of machine is suited for the ration packaging of small particulates, petty powder, and super-mini-power.

    The parts, which come into contact with filling material, are made of stainless steel conforming to GMP standard.

    Technical parameters


    No.ItemsPerformance
    01Power supply

    380V±10%or design according client requiremen

    02Power

    3kw

    03Air source

    0.6Mpa clean and stable compressed air

    04

    bottle

    design according customer's bottle and cap

    05filling head

    2

    06Filling productPowder, granular
    07Filling range5-1000g
    08Filling error

    ± 2%

    09Number of filling nozzles2 filling heads
    10Production capacity

    700-1200 bottle per hour

    11Machine weightabout 1200Kg
    12Machine dimension (L×W×H)

    2000mm (L)*800mm (W)*2100mm (H)



    The main components of this machine are all international famous brands. The human-machine interface and microcomputer controller (PLC) adopt the Japanese Panasonic brand. The operation is simple and the operation is reliable. The servo control system adopts Taiwan TECO and has been used by the company for nearly 10 years. Has considerable experience, stable quality, wide application environment and low maintenance rate. The main power inverter adopts the French Schneider brand


    An oil-water separator is installed in front of the intake main pipe. When the pressure is too high or too low, the host automatically alarms and stops the machine; (All the above alarms are touch screen display and sound and light alarms at the same time)


    The Photo Of Our Company

    Jiangsu Tom Group is an enterprise specializing in the production of pesticide / veterinary medicine, fertilizer and chemical intelligent equipment. The factory covers an area of 150 acres and has a construction area of 120,558 square meters. It has 710 employees, 2 doctoral students, 30 master students, and 358 undergraduates. It has obtained ISO9001 quality system. Certification, ISO14001 Environmental Management System Certification, OHSAS18001 Occupational Health and Safety System Certification, CE Certification, Jiangsu Province Specialized Specialized New "Little Giant" Enterprise, Changzhou Specialized Specialized New Small and Medium Enterprise, 125 National Utility Patents and 26 National Inventions patent. Over the past 24 years, after the hard work of Tom people, Tom Group has continued to innovate and develop, keeping pace with the times, providing generations of advanced intelligent packaging equipment for more than 3,300 pesticide / veterinary medicine, fertilizer and chemical companies, and building Industry 4.0 intelligent factories for customers; Provide automated three-dimensional warehouse; create smart factory production data acquisition and execution system (MES) for customers.
